How to Configure GRE VPN

Introduction

This network create a VPN tunnel between R1 and R2 using GRE tunneling protocol that can encapsulate a wide variety of protocol packet types inside IP tunnels. GRE creates a virtual point-to-point link to Cisco routers at remote points over an IP internetwork. Routing protocols can be used over a GRE tunnel just as though it were a point to point circuit.

Prepare the Network and Basic Configurations

Cable the network according the topology diagram.

Clear existing configurations on the routers.

Perform basic router configuration.

Configure Router and GRE Tunnel Interfaces

Configure R1, R2 and ISP routers with IP addresses and masks.

R1#configure terminal
R1(config)#interface f0/0
R1(config-if)#ip address 192.168.10.1 255.255.255.0
R1(config-if)#no shut
R1(config-if)#

R1(config)#interface s0/0/0
R1(config-if)#ip address 10.2.2.2 255.255.255.252
R1(config-if)#no shutdown
R1(config-if)#

R2#configure terminal
R2(config)#int s0/0/1
R2(config-if)#ip address 10.1.1.2 255.255.255.252
R2(config-if)#no shut
R2(config-if)#

R2(config-if)#int f0/0
R2(config-if)#ip address 192.168.20.1 255.255.255.0
R2(config-if)#no shut
R2(config-if)#end
R2#

ISP#configure terminal
ISP(config)#interface s0/0/0
ISP(config-if)#ip address 10.2.2.1 255.255.255.252
ISP(config-if)#no shutdown
ISP(config-if)#

ISP(config-if)#inte s0/0/1
ISP(config-if)#ip address 10.1.1.1 255.255.255.252
ISP(config-if)#no shut
ISP(config-if)#end
ISP#

Configure PC1 and PC2 with IP address and default gateway.

Configure GRE Tunnel interface on R1 and R2

R1(config)#interface tunnel 0
R1(config-if)#description GRE-Tunnel to R2
R1(config-if)#ip address 192.168.1.1 255.255.255.252

R1(config-if)#tunnel source 10.2.2.2
R1(config-if)#tunnel destination 10.1.1.2
R1(config-if)#end

Tunnel source is R1’s serial 0/0/0 interface and tunnel destination is R2’s serial 0/0/1 interface.

R2(config)#interface tunnel 0
R2(config-if)#description GRE-Tunnel to R1
R2(config-if)#ip address 192.168.1.2 255.255.255.252

R2(config-if)#tunnel source 10.1.1.2
R2(config-if)#tunnel destination 10.2.2.2
R2(config-if)#end

Tunnel source is R2’s serial 0/0/1 interface and tunnel destination is R1’s serial 0/0/0 interface.

Enable EIGRP with process ID 1 on R1 and R2

Advertise the LAN interface Fa0/0 and the tunnel interfaces on both R1 and R2. Do not advertise to ISP router.

R1(config)#router eigrp 1
R1(config-router)#no auto-summary
R1(config-router)#network 192.168.1.0 0.0.0.3
R1(config-router)#network 192.168.10.0 0.0.0.255
R1(config-router)#end

R2#conf ter
R2(config)#router eigrp 1
R2(config-router)#no auto-summary
R2(config-router)#network 192.168.20.0
R2(config-router)#network 192.168.1.0 0.0.0.3
R2(config-router)#end

Apply default route on R1 and R2

R1(config)#ip route 0.0.0.0 0.0.0.0 s0/0/0
R2(config)#ip route 0.0.0.0 0.0.0.0 s0/0/0

Before you configure authentication and encryption test that the network is working as planned. So that you will know what to troubleshoot incase you encounter a problem at the end and It is easier to troubleshootin before you apply authentication and encryption.

Check the interfaces on R1, R2, and ISP routers using show ip interface brief command.

R2#show ip int brief

Interface                  IP-Address      OK? Method Status                Protocol
FastEthernet0/0            192.168.20.1    YES manual up                    up
FastEthernet0/1            unassigned      YES unset  administratively down down
Serial0/0/0                unassigned      YES unset  administratively down down
Serial0/0/1                10.1.1.2        YES manual up                    up
Tunnel0                    192.168.1.2     YES manual up                    up

Use show ip route command to check the routing table on R1 and R2.

R1#show ip route

Codes: C - connected, S - static, R - RIP, M - mobile, B - BGP
      D - EIGRP, EX - EIGRP external, O - OSPF, IA - OSPF inter area
      N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
      E1 - OSPF external type 1, E2 - OSPF external type 2
      i - IS-IS, su - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
      ia - IS-IS inter area, * - candidate default, U - per-user static route
      o - ODR, P - periodic downloaded static route

Gateway of last resort is 10.2.2.1 to network 0.0.0.0

C    192.168.10.0/24 is directly connected, FastEthernet0/0
D    192.168.20.0/24 [90/26882560] via 192.168.1.2, 00:01:33, Tunnel0
    10.0.0.0/30 is subnetted, 1 subnets
C       10.2.2.0 is directly connected, Serial0/0/0
    192.168.1.0/30 is subnetted, 1 subnets
C       192.168.1.0 is directly connected, Tunnel0
S*   0.0.0.0/0 [1/0] via 10.2.2.1

Test connectivity using ping command between PC1 and PC2 or use extended ping from R1 LAN interface Fa0/0 to R2 LAN interface and vice-versa.

R2#ping ip
Target IP address: 192.168.10.1
Repeat count [5]:
Datagram size [100]:
Timeout in seconds [2]:
Extended commands [n]: y
Source address or interface: 192.168.20.1
Type of service [0]:
Set DF bit in IP header? [no]:
Validate reply data? [no]:
Data pattern [0xABCD]:
Loose, Strict, Record, Timestamp, Verbose[none]:
Sweep range of sizes [n]:
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 192.168.10.1, timeout is 2 seconds:
Packet sent with a source address of 192.168.20.1
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 36/36/36 ms

IPsec Encryption and Authentication

Configure an Internet Security Association and Key Management Protocol (ISAKMP) policy, an ISAKMP key, and an IPSec transform set. The ISAKMP policy, key, and IPSec transform set must match on both sides of a single tunnel.

R1(config)#crypto isakmp policy 1
R1(config-isakmp)#authentication  pre-share
R1(config-isakmp)#group 5
R1(config-isakmp)#encryption aes
R1(config-isakmp)#hash sha
R1(config-isakmp)#exit

R1(config)#crypto isakmp key 0 blindhog address 10.1.1.2

R1(config)#crypto ipsec transform-set aes-sha esp-aes esp-sha-hmac

Extended access control list that permit ip only from R2 serial 0/0/1 to R1 serial 0/0/0 interface.

R1(config)#access-list 101 permit GRE host 10.2.2.2 host 10.1.1.2

Configure the crypto map on R1

R1(config)#crypto map vpn 11 ipsec-isakmp
% NOTE: This new crypto map will remain disabled until a peer
       and a valid access list have been configured.

R1(config-crypto-map)#description VPN from R1 to R2

R1(config-crypto-map)#set peer 10.1.1.2

R1(config-crypto-map)#set transform-set aes-sha
R1(config-crypto-map)#match add 101
R1(config-crypto-map)#exit

R1(config)#int s0/0/0
R1(config-if)#crypto map vpn
R1(config-if)#end
R1#

R2(config)#crypto isakmp policy 1
R2(config-isakmp)#authentication pre-sha
R2(config-isakmp)#group 5
R2(config-isakmp)#encryption aes
R2(config-isakmp)#hash sha
R2(config-isakmp)#exit

R2(config)#crypto isakmp key 0 blindhog address 10.2.2.2

R2(config)#crypto ipsec transform-set aes-sha esp-aes esp-sha-hmac
R2(cfg-crypto-trans)#exit

Extended access control list that permit ip only from R1 serial 0/0/0 to R2 serial 0/0/1 interface.

R2(config)#access-list 102 permit GRE host 10.1.1.2 host 10.2.2.2

Configure the crypto map on R2

R2(config)#crypto map vpn 12 ipsec-isakmp
% NOTE: This new crypto map will remain disabled until a peer
       and a valid access list have been configured.

R2(config-crypto-map)#description VPN from R2 to R1

R2(config-crypto-map)#set peer 10.2.2.2

R2(config-crypto-map)#set transform-set aes-sha
R2(config-crypto-map)#match add 102
R2(config-crypto-map)#exit

R2(config)#int s0/0/1
R2(config-if)#crypto map vpn

R2(config-if)#end

Test and Verify VPN Connectivity

Use show ip route command on R1 to check that a route exist to 192.168.20.0/24 network through the tunnel interface. Do the same on R2 to verify that a route exist to 192.168.10.0/24 network through the tunnel interface.

R2#show ip route
Codes: C - connected, S - static, R - RIP, M - mobile, B - BGP
      D - EIGRP, EX - EIGRP external, O - OSPF, IA - OSPF inter area
      N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
      E1 - OSPF external type 1, E2 - OSPF external type 2
      i - IS-IS, su - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
      ia - IS-IS inter area, * - candidate default, U - per-user static route
      o - ODR, P - periodic downloaded static route

Gateway of last resort is 10.1.1.1 to network 0.0.0.0

D    192.168.10.0/24 [90/26882560] via 192.168.1.1, 00:13:17, Tunnel0
C    192.168.20.0/24 is directly connected, FastEthernet0/0
    10.0.0.0/30 is subnetted, 1 subnets
C       10.1.1.0 is directly connected, Serial0/0/1
    192.168.1.0/30 is subnetted, 1 subnets
C       192.168.1.0 is directly connected, Tunnel0
S*   0.0.0.0/0 [1/0] via 10.1.1.1

Use ping or extended ping command to test connectivity between 192.168.10.0/24 and 192.168.20.0/24 network.

R1#ping ip

Target IP address: 192.168.20.1
Repeat count [5]:
Datagram size [100]:
Timeout in seconds [2]:
Extended commands [n]: y
Source address or interface: 192.168.10.1
Type of service [0]:
Set DF bit in IP header? [no]:
Validate reply data? [no]:
Data pattern [0xABCD]:
Loose, Strict, Record, Timestamp, Verbose[none]:
Sweep range of sizes [n]:
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 192.168.20.1, timeout is 2 seconds:
Packet sent with a source address of 192.168.10.1
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 36/36/36 ms

Use show crypto engine connections active, show crypto map and show crypto ipsec sa command s to verify connection.

R2#show crypto engine connections active

Crypto Engine Connections ID Type Algorithm Encrypt Decrypt IP-Address

   1  IPsec   AES+SHA                   0       81 10.1.1.2
   2  IPsec   AES+SHA                  82        0 10.1.1.2
2001  IKE     SHA+AES                   0        0 10.1.1.2

R2# show crypto map

Crypto Map "vpn" 12 ipsec-isakmp

       Description: VPN from R2 to R1
       Peer = 10.2.2.2
       Extended IP access list 102
           access-list 102 permit gre host 10.1.1.2 host 10.2.2.2
       Current peer: 10.2.2.2
       Security association lifetime: 4608000 kilobytes/3600 seconds
       Responder-Only (Y/N): N
       PFS (Y/N): N
       Transform sets={
               aes-sha:  { esp-aes esp-sha-hmac  } ,
       }
       Interfaces using crypto map vpn:
               Serial0/0/1

R2#show crypto ipsec sa

interface: Serial0/0/1

   Crypto map tag: vpn, local addr 10.1.1.2

  protected vrf: (none)
  local  ident (addr/mask/prot/port): (10.1.1.2/255.255.255.255/47/0)
  remote ident (addr/mask/prot/port): (10.2.2.2/255.255.255.255/47/0)
  current_peer 10.2.2.2 port 500
    PERMIT, flags={origin_is_acl,}
   #pkts encaps: 304, #pkts encrypt: 304, #pkts digest: 304
   #pkts decaps: 302, #pkts decrypt: 302, #pkts verify: 302
   #pkts compressed: 0, #pkts decompressed: 0
   #pkts not compressed: 0, #pkts compr. failed: 0
   #pkts not decompressed: 0, #pkts decompress failed: 0
   #send errors 168, #recv errors 0

    local crypto endpt.: 10.1.1.2, remote crypto endpt.: 10.2.2.2
    path mtu 1500, ip mtu 1500, ip mtu idb Serial0/0/1
    current outbound spi: 0x192C42F5(422331125)
    PFS (Y/N): N, DH group: none

    inbound esp sas:
     spi: 0xF0333FAE(4029890478)
       transform: esp-aes esp-sha-hmac ,
       in use settings ={Tunnel, }
       conn id: 1, flow_id: AIM-VPN/SSL-1:1, sibling_flags 80000046, crypto map: v
       sa timing: remaining key lifetime (k/sec): (4473306/2869)
       IV size: 16 bytes
       replay detection support: Y
       Status: ACTIVE
       inbound ah sas:
       inbound pcp sas:

    outbound esp sas:
     spi: 0x192C42F5(422331125)
       transform: esp-aes esp-sha-hmac ,
       in use settings ={Tunnel, }
       conn id: 2, flow_id: AIM-VPN/SSL-1:2, sibling_flags 80000046, crypto map: v
       sa timing: remaining key lifetime (k/sec): (4473305/2869)
       IV size: 16 bytes
       replay detection support: Y
       Status: ACTIVE
       outbound ah sas:
       outbound pcp sas:
